Semi-automatic screw weigher DSH
Semi-automatic screw weigher DSH
Semi-automatic screw weigher DSH
Semi-automatic screw weigher DSH
Semi-automatic screw weigher DSH

Semi-automatic screw weigher DP2-0.5 is used for dosing of hard-flowing, dust-forming products in pharmaceutical, chemical and food industry (pharmaceutical powders, milled spices, ground coffee, cocoa, sweeteners, etc.) into prepared package: cans, bags, boxes. More...
Video








Send an enquiry

Description

Technical parameters

Video

Semi-automatic screw weigher DP2-0.5 is used for dosing of hard-flowing, dust-forming products in pharmaceutical, chemical and food industry (pharmaceutical powders, milled spices, ground coffee, cocoa, sweeteners, etc.) into prepared package: cans, bags, boxes.

Advantages of the weigher:

  • Stable construction
  • Powerful servomotor with a high torque
  • Separate drive for mixer and screw (to obtain high precision)
  • Quick-change screw (to get another dose)
  • Programmable controller with LCD display
  • Memory for 10 products
  • Setting up of the dosing regime according to 6 parameters

Information is for reference only. For more details please contact our sales managers.


Model DSH2-0,5 DSH2-5,0
Dose limit 1-500 g. (changing the screws) 20 -5000 g. (changing the screws)
Dosing accuracy grade of accuracy 0,5 according to GOST 10223-97
Dosing speed from 4 to 12 packets per minute. Depends on operator’s work, product type, dose, container type.
Electrical power supply 3 phases 380V 50Hz 3 phases 380V 50Hz
Power input 1.1 kW 1.6 kW
Weight 130 kg 180 kg
Dimensions (length x width x height) 830x780x1800 mm 890x1100x1800 mm
Hopper volume 25 litres 35 litres

Technical parameters are for reference only. For more details please contact our sales managers.
