Pallet dispenser, model MVP-15

The machine is designed for delivering pallets from the stack. More...

+44 7520 64 26 44 (Great Britain) +33 755 54 87 42 (France)

Send an enquiry

Description

Technical parameters

Video

The machine is designed for delivering pallets from the stack. It can operate both in semi-automatic mode with pallet’s output one by one from the stack, and in automatic mode with pallets’ output to roller tables and conveyors after sensor signal from the line. The system can be adjusted from one size to another in easy way.

Information is for reference only. For more details please contact our sales managers.

Delivery speed	up to 12 pallets per min
Pallet size	800(1000) x 1200 mm
Pallet qty in stack	up to 15 pcs
Pneumatic supply	0,6 bar
Air consumption each pallet	38 NL
Weight	about 280 kg
Overall size (LxWxH)	1580 x 1530 x 1420 mm

Roller table of the pallet line:

Technical parameters are for reference only. For more details please contact our sales managers.
